Accessories for TOC/TNb Analysis

Accessories for TOC/TNb Analysis

MARCA: Analytik Jena

TOC Analysis in Liquids TOC Analysis in Solids

Consulte
Sampler for TOC analysis in liquids

APG 10 autosampler for multi N/C® 3100, UV HS, pharma

Automatic sampler for 10 vials á 50 mL

APG 21 autosampler for multi N/C® 3100, UV HS, pharma

Automatic sampler for 21 vials á 50 mL

APG 64 autosampler for multi N/C® 3100

Automatic sampler for up to 64 vials á 30 mL or up to 116 vials á 12 mL. Each sample is individually stirred and homogenized with a contamination-free magnetic stirrer prior to sampling. This is particularly important for the analysis of samples containing particles. The stirring speed is adjustable to 10 levels selected by the software.

APG 60 autosampler for multi N/C® 2100, 2100 S

Autosampler for up to 60 vials á 8 mL or up to 112 vials á 2 mL. Each sample is individually homogenized with a contamination-free magnetic stirrer prior to sampling. A wash position is also activated by software. Each sample can be individually stirred which is particularly important for the analysis of samples containing particles.

APG 49 autosampler for multi N/C® UV HS, pharma

Automatic sampler for up to 49 vials á 100 mL. Each sample is individually stirred and homogenized with a contamination-free magnetic stirrer prior to sampling. The stirring speed is adjustable to 10 levels selected by the software.

EPA sampler with piercing function

Automatic sampler with 64 positions for EPA sample vessels (septum-sealed with screw-top) á 40 mL. Each sample is individually stirred and homogenized with a contamination-free magnetic stirrer prior to sampling. Special piercing canulas are used to take the samples from the sealed vessels. They also allow the samples to be blown out inside the sealed vessel.

Swab test module

The swab test module for the TOC analyzer multi N/C® pharma HT is a module for the direct determination of carbon for cleaning validation by "swab procedure".

POC module "basic" or "automatic"

For manual or automated operation

ChD or CLD – chemiluminescence detector (CLD) or the solid state chemodetector (ChD)

For TNb determination

TOC Solids Module

TOC solids module HT 1300

High-temperature solids combustion system for the analyzers multi N/C® 2100, 2100 S, 3100 and multi N/C® UV HS (carbon analysis) – Solids module with combustion furnace for the analysis of carbon in solids with sample gas supply system and basic device connection kit. The furnace temperature is adjustable up to 1.300 °C, weighed portions of up to 3 g.

TIC solids module

For direct analysis of TIC in solids

Double furnace technology for multi N/C® 2100, 2100 S

Liquids and solids can be analyzed without the need for an additional furnace, simple operation and quick changeover from liquid to solid analysis and vice versa.
